1 HP single dust collector
2 HP single beg dust collector
3 HP single beg dust collector,
3 HP double beg dust collector,
5 HP double beg dust collector,
7.5 HP four beg dust collector
PORTABLE DUST COLLECTOR
Mahesh Fabricators Established in the year 2005, at Ahmedabad(Gujarat india). We are designer and manufacturer of industrial fans and blowers of best quality range of portable dust collector from 1 hp to 10 hp in single beg dust collector, double beg dust collector and four beg dust collector.
We are also providing Industrial centralize dust collector as per customer requirement.
Mahesh fabricators dust collector manufacturer in India. Portable dust collector manufacturer in Ahmedabad
Portable dust collector use in grinding and polishing units, Soldering and welding units, sugar industries, wood working machineries, CNC Machine dust collector, VMC Machine dust collector, Saw dust collection, floor dust collection systems, single beg dust collector, double beg dust collector.
Appication of PORTABLE DUST COLLECTOR
Features of PORTABLE DUST COLLECTOR
| PORTABLE DUST COLLECTOR | ||||||
| SPECIFICATION | 1 HP | 2 HP | 3 HP X 1B | 3 HP X 2B | 5 HP | 7.5 HP |
| MDL NO. | MDC-131 | MDC-231 | MDC-331 | MDC-332 | MDC-532 | |
| AIRFLOW | 800 CFM | 1900 CMH | 2300 CMH | 2300 CMH | 3000 CMH | 4500 CMH |
| STATIC PRESSURE | 185 WC MM | 225 WC MM | 250 WC MM | 250 WC MM | 250 WC MM | 250 WC MM |
| OP. TEMP | 80 DEG C’ | 80 DEG C’ | 80 DEG C’ | 80 DEG C’ | 80 DEG C’ | 80 DEG C’ |
| IMPELLER DIA | 10” (250MM) | 12.7” (322 MM) | 14.5”(355MM) | 14.5”(355MM) | 16”(400MM) | 17.2” (450) |
| MOTOR HP | 1 HP/2800RPM | 2 HP/2800 RPM | 3 HP/2800RPM | 3 HP/2800RPM | 5 HP/2800RPM | 7.5 HP/2800RPM |
| INLET DIA | 4” X 1NOS | 4” X 2NOS | 4” X 2NOS | 4” X 2NOS | 4” X 3NOS | 4” X 4NOS |
| FILTER BEG SIZE | 14” X 24” | 18” X 39” L | 18” X 39” | 18” X 39” L | 18” X 39” L | 18” X 48” L |
| FILTER BEG | 1 NOS | 1 NOS | 1 NOS | 2 NOS | 2 NOS | 2 NOS |
| COLLECTING BEG | 1 NOS | 1 NOS | 1 NOS | 2 NOS | 2 NOS | 2 NOS |
| UPPAR BEG | 101 P.P GRAY Cotton | 101 P.P GRAY Cotton | 101 P.P GRAY Cotton | 101 P.P GRAY Cotton | 101 P.P GRAY Cotton | 101 P.P GRAY Cotton |
| OVERALL DIMENSION< | 24”(L)X20”(W)X56”(H) | 39”(L)X24”(W)X92”(H) | 38”(L)X24”(W)X80”(H) | 50”(L)X24”(W)X92”(H) | 50”(L) X 25” (W) X 92”(H) | 55”(L) X 26” (W) X 110”(H) |
| WEIGHT | 48 KG APPROX | 60 KG | 64 KG | 75 KG | 95 KG | 140 KG |
